    HARMSCO-801-20

    Harmsco 801-20 Water Filter Cartridge (Blue End Cap)

    format_list_bulleted Features & Specs
    Package Qty: 1
    Manufacturer: Harmsco
    Manufacturer's Id: 801-20
    UPC: 799705706040
    Actual Size (in): 9 3/4 inches (length) x 2 3/4 inches (outside diameter) x 1 1/16 inches (inner diameter)
    Media: Polyester-Plus
    Primary Filter Media: Pleated Fabric
    Brand: Harmsco
    Advertised Size: 10 x 2-1/2
    Inside Diameter (in): 1.06 in
    Length (in): 9.75 in
    Outside Diameter (in): 2.75 in
    Maximum Temperature (f): 140
    Media Square Feet: 6
    Media Type: Sediment Filter
    Country of Origin: United States
    Micron Rating Nominal: 20
    Flow Rate (gpm): 4.0
    description Instructions
    1. The Harmsco 801-20W filter cartridge should be replaced when the filter fills up with sediment and the flow rate decreases
    2. Temperature limits vary and depend on pressure and time under load

    The Harmsco 801-20W water filter is a 20 micron, highly efficient filter cartridge made of pleated Polyester-PlUSFilter media for low pressure drop, high flow cap. The Harmsco 801-20W water filter's pleated design offers up to 50% more surface area than competitive filters resulting in superior performance and increased contaminant removal, and longer filtration runs for fewer changeouts and less maintenance. Low pressure drop. Thermally bonded for longer usable life. FDA approved materials--NSF 61 certified and has an Engineered media for superior performance.


    HARMSCO-801-20   is comparable with the following part number(s)

    • 801-20HT
    • 801-20
