    INLINE-WATER-FILTERS-85470

    Washing Machine Inline Water Filter 85470

    format_list_bulleted Features & Specs
    Package Qty: 1
    Manufacturer: Inline Water Filters
    Manufacturer's Id: 85470
    UPC: 852698001858
    Actual Size (in): 3 inches (Length) x 2 inches (Width)
    Brand: Inline Water Filters
    Length (in): 3 in
    Width (in): 2 in
    Maximum Temperature (f): 320
    Country of Origin: United States
    Micron Rating Nominal: 25
    Flow Rate (gpm): 4.5
    description Instructions
    1. If the water is slow due to your inlet valve being clogged from sediment, you will need to clean the screen before installing the washing machine filter
    2. See your owner's manual for cleaning instructions. The washing machine filter will eliminate future buildup on the screen
    3. Disconnect the hose from the faucet on the initial installation. Attach the filter directly to the cold or hot water faucet and attach the hose, as pictured on the package
    4. When you first install the filter or replace the cartridge, turn off the water faucets and turn on the washing machine for a minute. This drains the water out of the lines and eliminates the clean up
    5. When changing the cartridge, unscrew the middle of the filter housing, remove the old, replace with the new and screw back together. It's very easy and simple to change
    6. You can install the washing machine filter on either the hot or cold water intake
    7. There is an optional adapter hose for the washing machine water filter hook-up. Use when limited space or alignment of the filter is a problem
    filter_alt Filter Life
    Filter Life (months): 3 months

    The manufacturer survey indicates this screen should be cleaned every 3-12 months for homeowners on well water. This screen is located behind the machine at the base of the water line and requires the machine to be pulled out, hoses disconnected, the screen carefully removed and cleaned. After extensive research to evaluate the problem of clogged inlet valve screens, Inline Water Filters has taken the initiative to design a Washing Machine Sediment Filter for the sole intent of removing solid sediment prior to reaching the screen destination. With the average household washing 10 loads of laundry weekly, using 15,000 gallons of water yearly, this problem is especially troublesome for the 17,000,000 homeowners on well water. Our tests indicate that the use of a whole house filter lessens the problems, however doesn't prevent it as the smaller particles get through and coat the screen over time. As this screen gets contaminated, the water flow slows, adding extended time to the wash cycle and distorting the water temperature. In extreme cases, the sediment gets trapped between the solenoid, allowing the water to continue to flow, creating flooding. The Washing Machine Inline Water Filter 85470 eliminates the need to clean the inlet valve screen, allowing water to run freely. The washing machine sediment filter attaches directly to the washing machine water faucets for either hot or cold intake. The Maximum Temperature is 320 degrees Fahrenheit or 160 degrees Celsius. Prevents inconsistent water temperature due to restricted water intake, created from a clogged inlet screen. The washing machine filter comes complete with a replacement cartridge, ready to install. No tools required. Quick and easy cartridge replacement.


    INLINE-WATER-FILTERS-85470   is comparable with the following part number(s)

    • 85470
